Advanetch 6-ch Relay Output EtherNet/IP Module (ADAM-6160EI-AE)
Rp8.379.168
Deskripsi
SPECIFICATIONS
| Category | Attribute | Value |
| General | Connectors | 2 x RJ45, 1 x 15-pin plug-in screw terminal, 1 x 5-pin plug-in screw terminal |
| General | Protocol | Ethernet/IP |
| Communications | Interface | Ethernet |
| Environment | Isolation Voltage | 2,500 VDC |
| Environment | Operating Temperature | -10~70 °C (14~158 °F) |
| Relay Output | Channels | 6 |
| Relay Output | Contact Rating (Resistive) | 5 A @ 30 VDC, 5 A @ 250 VAC |
| Relay Output | Relay Type | 1 x Form A, 5 x Form C |
| Power Requirements | Input Voltage | 10~30 VDC |
