Advantech 10 kS/s, 12-bit, 8-ch Multifunction USB Module (USB-4702-AE)
Deskripsi
| Category | Attribute | Value |
| Analog Input | Channels | 8 |
| Analog Input | Input Range | ±20 V, ±10 V, ±5 V, ±4 V, ±2.5 V, ±2 V, ±1.25 V, ±1 V |
| Analog Input | Resolution(Bits) | 12-bit |
| Analog Input | Sampling Rates(S/s) | 10 KS/s (sum) |
| Analog Output | Channels | 2 |
| Analog Output | Output Ranges | 0~5 V |
| Analog Output | Output Type | V |
| Analog Output | Resolution | 12-bit |
| Analog Output | Update Rate(S/s) | Static update |
| General | Humidity (Operating) | 5~95% RH (non-condensing) |
| General | Humidity (Storage) | 5~95% RH (non-condensing) |
| General | Programming Language | C#, C++, LabVIEW, VB.Net, BCB, MFC, VB6, Delphi, Java, Matlab, Qt |
| Counter/Encoder Input | Channels | 2 |
| Counter/Encoder Input | Counting Range | 32-bit |
| Counter/Encoder Input | Max. Input Frequency | 5 MHz |
| Digital Input | Channels | 8 (TTL) |
| Digital Output | Channels | 8 (TTL) |
Informasi Tambahan
| Brand | Advantech |
|---|
