Advantech Compact Embedded 3.5″ SBC Chassis (ACK-A001E)
- 3.5″ SBC chassis supports front & rear I/O interfaces
- Fanless system with wall-mount & desk mount support, w/ removable mounting flange
- Bottom door to access the solder side of the board
- Flexible cutout I/O in the rear bezel up to 4 x COM , 4 x USB, audio, and LPT/PS2/LVDS
- Easy assembly & maintenance of 2.5″ hard disk
- Supports dedicated Advantech 3.5″ SBCs: PCM-9362 or PCM-9363
- Versatile power supply options
Deskripsi
| Category | Attribute | Value |
| Form Factor | Board | 3.5″ SBC |
| Miscellaneous | Control | Power switch (Push-on/off type) |
| LED Indicators | Power, HDD | |
| Environment | Humidity | 40C at 95% RH Non-Condensing |
| Operational Temperature | 0 ~ 40C (32 ~ 104F) | |
| Vibration Resistance | 1 Grms (w/o 2.5′ HDD) | |
| Front I/O Interface | COM | 1 (1xRS-232) |
| RJ-45 | 2 | |
| USB | 2 | |
| VGA | 1 | |
| Rear I/O Interface | Antenna | 1 |
| Audio | 3 (Mic-In, Line-Out, Line-in) | |
| Circular cutouts | 1 (Reserved for LVDS, PS/2 & LPT cable) | |
| COM | 2 (1 x RS-232, 1 x RS-232/422/485) | |
| USB | 4 | |
| Certification | EMC | CE/FCC |
| Disk Drive Bay | 2.5″ Internal | 1 |
| Physical | Dimension (mm) | 200 x 60 x 145 mm with mounting bracket: 230 x 65 x 145 mm |
| Weight | 0.95 kg (2.09 lb) |
Informasi Tambahan
| Brand | Advantech |
|---|
