Advantech ULI-234TCL – RS-485 (Terminal Block) Isolator
Deskripsi
SPESIFICATION
| Category | Attribute | Value |
| General | Isolation | 2kV |
| General | Mounting | Inline |
| General | Power | 10-14VDC |
| General | Serial Type | RS-422/485 |
| General | Technology | Serial |
| General | Temperature | 0 to 40C |
| Power | Power Input (DC) | 10 – 14 VDC |
| Protection | Isolation | 2,000 VDC |
| Protection | Surge Protection | 600W |
| Serial Communication | Maximum Serial Transmission Speed | 115.2 Kbps |
| Serial Communication | Repeater Maximum Distance | 1.2 Kilometers |
| Serial Communication | Serial Port Connector Type | Terminal block |
| Serial Communication | Serial Port Number | 1 |
| Serial Communication | Serial Standard | RS-422 / RS-485 |
| Environment | Temperature (Operating Range) | 0 ~ 40°C (32 ~ 104°F) |
| Accessory General | Mounting | Inline |
Informasi Tambahan
| Brand | Advantech |
|---|
