Dahua Outdoor Long Range 5G Wireless Bridge (DH-PFM886-15)
*Harga Hubungi Kami
- Use the high-performance 802.11ac MIMO chip, and the highest rate can achieve
- 867Mbps in theory
- Supports 5 working mode: Access Point, Client, WDS Access Point, WDS Client, WDS Repeater
Deskripsi
Deskripsi Dahua Outdoor Long Range 5G Wireless Bridge (DH-PFM886-15)
Model |
DH-PFM886-15 |
Wireless Features |
|
| Wireless Standard | IEEE802.11 a/n/ac |
| Working Frequency | 5745~5825MHz (support frequency to extend, extended range: 4920~6100MHz) |
| Wireless Speed | 867Mbps |
| Modulation Mode | OFDM |
| Antenna | 23dBi |
| Output Power | 27dBm (max) |
| Receiving Sensitivity | 11a： 6Mbps -91 dBm 54 Mbps -72dBm 11n： MCS0 -85 dBm MCS7 -67dBm 11ac：MCS0 -85 dBm MCS9 -60dBm |
| Transmission Distance | ≤15km |
| Wireless Direction Angle | Horizontal 10°, vertical 10° |
Hardware |
|
| Power | 1*PoE RJ45 (PoE input via PoE switch or PoE adapter) |
| Power Consumption | ≤25W |
| Ethernet Port | 1×10/100M/1000MBase-TX (Cat. 5/5E, RJ-45) |
| Indicator Light | 3×Link Quality |
| Working Temperature | -30℃～+70℃ |
| Storage Temperature | -40℃～+85℃ |
| Working Humidity | 5%～95%RH(no condensation) |
| Equipment Dimension | 240mmⅹØ373mm |
| Equipment Weight | 0.94kg |
| Protection Level | IP66 |
Software |
|
| Encryption Type | 802.1x/WPA-PSK/WPA2-PSK |
| Network Mode | Route/Network Bridge |
| Working Mode | Access Point/Client/WDS AP/WDS client/WDS Repeater |
| Security Mechanism | IP/MAC address filtering, hide network name |
| Network Protocol | TCP/UDP/ARP/ICMP/DHCP/HTTP/NTP |
| TDMA Enhancement | Support |
| Auto ACK Timing Adjustment | Support |
| Management and Log | NTP，Syslog，Telnet，AC，SNMP |
| Webpage Configuration Management | Web, SNMP, Access Controller |
| Firmware Update | Web, Access Controller |
| Bandwidth Flexible Configuration | 10/20/40/80MHz |
