voltage release – iMNs – tripping unit – 220..240 VAC
Rp1.149.782
Deskripsi
| range of product | Acti9 |
|---|---|
| Product or component type | Undervoltage release |
| device short name | IMNs |
| [Uc] control circuit voltage | 220…240 V AC 50/60 Hz |
| Control type | Delayed |
| 9 mm pitches | 2 |
| Range compatibility | Acti 9 (Acti9 iC65) Acti 9 (Acti9 ARA) Acti 9 (Acti9 iDPN Vigi) Acti 9 (Acti9 iID) Acti 9 (Acti9 iSW-NA) Acti 9 (Acti9 RCA) Acti 9 (Acti9 iDPN (China version)) Acti 9 (Acti9 iC60) double terminals miniature circuit breaker Acti 9 (Acti9 iC40) |
|---|---|
| Local signalling | Action indicator |
| Mounting mode | Clip-on |
| Mounting support | DIN rail |
| Comb busbar and distribution block compatibility | Top and bottom: YES |
| Width | 18 mm |
| Colour | White |
| Connections – terminals | Clamp terminal – 1 cable(s) 10 mm² – rigid Clamp terminal – 2 cable(s) 2.9 mm² – rigid Clamp terminal – 1 cable(s) 8 mm² – flexible Clamp terminal – 2 cable(s) 2.9 mm² – flexible with cable end |
| Tightening torque | 1 N.m |
| Compatibility code | IMNs |
